Kelly is an American company that has been producing motor controllers for over 10 years. The quality and reputation of these controllers are at the highest level, the manufacturer gives a 12-month warranty.
Attention! If you look at the options for this controller model on the official Kelly website, you will see that for an additional 10% of the cost, the manufacturer offers the CAN option. But this is not control, but only data reception (telemetry), so if you buy a controller directly from the manufacturer, you will not be able to control it via CAN.
We have developed firmware (actual version PRI7235NC) that allows you to fully control via CAN, and we install it in each controller.
lly models with such control for other currents are also available (models from 120A to 1200A), please specify by phone for more details.
Today, this is the best controller for ground drones, because the only competitor is VESC Flipsky, but they often burn out.
Characteristics and features:
- Sinusoidal signal allows for very precise motor control, no noise, maximum efficiency, torque, and the ability to start smoothly from a standstill.
- Support for motors with any number of poles.
- Operating temperature range: -40 to 80℃ (MOSFET temperature).
- Phase current: 450A
- Max battery current: 320A
- Continious battery current: 160A
- If necessary, we install firmware with the field weakening option for an additional fee.
- Suitable for: electric motors with a rated power of 1kW-8kW.
Bluetooth or programming cable is sold separately.
